Analog Drum Synth PCB – Inspired by the Rare Kenwood KR-6170

Discover a true analog drum synthesizer PCB, inspired by the extremely rare Kenwood KR-6170, created for musicians, builders, and sound designers who demand authentic vintage tone and character.

This PCB has been carefully designed and manufactured, focusing exclusively on the analog drum synthesizer section, preserving the soul and sonic identity of the original circuit.

🔊 Inductor-Based Analog Sound

Unlike modern digital or IC-heavy designs, this drum synthesizer uses inductors (coils) in its sound generation stages, delivering:

Warm, organic, and punchy analog tone
Unique transient response and natural decay
A character that cannot be accurately replicated digitally
The required inductors are available from Tsomokos Audio and can be supplied upon request.

🥁 Six Analog Drum Voices

The PCB features six independent analog drum sounds, making it ideal for:

Vintage-style drum machines
Modular or semi-modular systems
Studio sound design
Experimental and DIY synth projects
⚙️ Integrated Circuits & Controls

This is a complete and self-contained PCB, including:

Power supply circuit
Protection circuit
Master volume control
Internal mixer for all drum voices
Studio-quality analog Baxandall EQ
Bass control
Treble control
The Baxandall equalizer provides smooth, musical tone shaping, perfect for enhancing drum sounds without harshness.

📦 Parts Availability

All electronic components are available directly from our store.
Upon request, we can supply:

Full component kits
Inductors (via Tsomokos Audio)
PCB + parts bundle options
(Components and shipping available at additional cost)

🎛️ Perfect For

✔ DIY synthesizer builders
✔ Drum machine designers
✔ Vintage audio enthusiasts
✔ Recording studios
✔ Sound designers & experimental musicians

⭐ Why Choose This PCB

Rare vintage-inspired design
Fully analog signal path
Inductor-based sound
